WINE595T-BB-DZ
Dual Temperature Upright Wine Display
H × W × D
1760 × 590 × 680mm
Energy (24hr)
0.488 kWh
Temperature
5 / 18°C
Capacity
428L
- Dual temperature zone (twin evaporator)
- Temperature can be adjusted to suit red and white wine
- Store and display up to 75x 75cl bottles in the top section and 78x 75cl bottles in the bottom section (153 total) (different bottle sizes may affect capacity)
- Beech shelves with anti-mould coating
- Digital controller and temperature display
- LED interior lights for each compartment - switch between white, blue or orange (orange LED helps reduce UV damage to the wine)
- “Frameless" edge-to-edge glass door
- Carbon filter to help reduce odours in the fridge from tainting the wine
- Humidity tray to help prevent corks drying out
- Front ventilation to enable unit to be built-in
- Door open alarm
- Low E, double glazed, tempered glass
- Lock
Downloads
Specifications
| External Height (mm) | 1760 |
| External Width (mm) | 590 |
| External Depth (mm) | 680 |
| Packed Height (mm) | 1815 |
| Packed Width (mm) | 660 |
| Packed Depth (mm) | 760 |
| Net Weight (kg) | 105 |
| Gross Weight (kg) | 116 |
| Gross Volume (L) | 428 |
| Wine Bottle 75cl | Top 75, Bottom 78 |
| Exterior Finish | Black |
| Interior Finish | Black |
| Lock | Yes |
| Lighting | LED |
| Feet / Castors | Adjustable Feet |
| No Of Shelves | Base + 14 |
| Shelf Type | Beech shelves with anti mould coating |
| Door Type | Right Hand Hinge |
| Reversible Door | Yes |
| Door Self Closing | No |
| Glazing | Double Glazed |
| Tempered Glass | Yes |
| Temperature Display | Digital |
| Controller | Digital |
| Power Switch | Yes |
| Light Switch | Yes |
| Noise Level (dBA) | 41 |
| Temperature Range (°C) | 5 / 18 |
| Max Ambient | 38 |
| Climate Class | N, SN, ST |
| Temperature Class | 4,6 |
| Refrigerant | R600a |
| Refrigerant Charge (g) | 61 |
| Insulation Type | Cyclopentane |
| Evaporator | Finned |
| Condensor | Wire On Tube |
| Energy Rating | G |
| Energy Consumption (kWh/24hr) | 0.488 |
| Annual Energy Consumption (kWh) | 178 |
| Power Supply | 13 Amp |
| Input Power (W) | 140 |
| Running Current (Amps) | 1.2 |
| Voltage Frequency | 220-240V~ 50Hz |
